Linet Eleganza 1

The Eleganza 1 bed has full electric positioning and brings the range of sophisticated functions intended for acute health care into the area of longterm care, adapting them for different care units. The main advantages of the Eleganza 1 nursing care bed are an aesthetically pleasing design, a high degree of safety parameters and support for convalescence.

Your benefits at a glance

Longevity of design and construction

The construction of Eleganza 1 is simple and highly durable. Moreover, the elevators are equipped with electric protection against overload, therefore the bed will automatically stop when an elevator is overloaded.

Comfortable for the tallest of patients

The Eleganza 1 hospital bed can be extended by 15 cm. To provide comfort to all patients, the standard width of the mattress platform is 90 cm.

Easier transportation

The 5th castor makes transporting the bed through long corridors easier, maintaining a straight line. In addition, the castor creates a turning point in the center of the bed.

The safe package (protector + extender)

To ensure a higher level of patient protection, the nurse can equip the Eleganza 1 bed with an independent protector and extension. The protector will automatically lock the side rail in the ‘up’ position.

Cardiac Chair

The position of the cardiac chair can be easily adjusted by using a single button to maximise the respiratory function and cardiac output.

Safe siderails

The bed can be equipped with soft drop function of split plastic siderails. The safety of the split plastic siderails is guaranteed by a systém of two independent unlocking movements. Siderails are lowered using the soft drop function which applies a gas spring to soften the effect of the siderails movement.

Technical features

Outer dimensions (siderails up) 218 cm x 99.5 cm
Mattress platform extension 15 cm
Recommended mattress size 200 cm x 90 cm x 16 cm
Max. mattress height 16 cm
Bed height 37 cm – 73.5 cm (39.5 – 76 cm with ⌀150 mm castors)
Maximum backrest angle 70°
Maximum thigh rest angle 35°
Trendelenburg/Reverse Trendelenburg position 15° / 15°
Ergoframe 10 cm / 6 cm
Height of plastic split siderails 38 cm
Height of single collapsible siderails 38 cm
Weight (basic equipment) 135 kg
Safe working load 185-250 kg
Lifting pole bearing capacity 75 kg
Max. patient weight 185 kg

Basic positioning and adjustments

Height adjustment motors
TR/ATR tilt adjustment motors
Backrest adjustment motor
Thighrest adjustment motor
Calfrest mechanical ratchet
Bed extension mechanical

Control elements

  • Patient controls in the side rails
  • Handset
  • Plug and play hand set
  • Central control panel (mini ACP)
  • Supervisor panel
  • Foot controls
  • Satellite control panel

Side Rails Concept

  • Plastic siderails with soft drop function
  • Ergonomic single collapsible side rails
  • Protector  (O)
  • Safe gap concept (entrapment prevention)

Mattress platform

  • 4-section mattress platform
  • Ergoframe 10 + 6 cm
  • Removable plastic covers formed from 8 removable blow moulded lamella

General Concept

  • Scissor construction


Mobilisation Elements

  • Mobi-Stick handles (O)

Castors and Brakes

  • 4 castors ⌀125 mm Tente Motion
  • 4 castors ⌀150 mm Tente Integral (O)
  • 4 castors ⌀150 mm Tente Integral with plastic covers (O)
  • 4 double castors ⌀150mm Tente Integral (O)
  • Centrally operated castors from 2 points
  • Centrally operated castors from 4 points (O)
  • 5th castor (O)

Special features

  • Brake alarm
  • Night light
  • Motor protection (independent current protection for each motor preventing damage to the motor if overloaded)

Bed ends

  • Removable plastic bed ends E1 design
  • Powder coated bed ends with colour HPL panel
  • Head and foot end with safety locks
